It consist of an inbuilt prefilter & very high exchanging capacity non-corrosive CATION & ANION Resin, columns prefilled with imported Resins for efficient results having treated water parameters. Fitted with a sturdy PVC multi control valve & can be connected direct to water taps. Fitted with analog / digital conductivity meter. Supplied with one plastic chemical proof regeneration tank & the complete unit is housed in a painted M.S. trolly for easy mobility. Features: • Digital Display • Non corrosive Regeneration Tank •In Built Pre filter High capacity Cation and Anion exchange resins. Upflow treatment. Easily portable - metal stand and trolley Can be connected direct to Water Tap. Simple Periodic regeneration - negligible operating costs. Digital model is fitted with digital conductivity meter. Treated water will have the conductivity less than 10 ms/cm and pH of 7.5-9 • Available in Double Bed, Four bed and Mixed bed models Capacity: 50 Ltrs / Hr. 70 Ltrs / Hr. 100 Ltrs / Hr. 200 Ltrs / Hr. 500 Ltrs / Hr.

The vacuum pump functions by removing the molecules of air and other gases from the vacuum chamber. It is available in single-stage & Double Stage with oil & belt Motor System. It is designed for accurate measurement of melting points and for checking the melting range of the solid samples & boiling points also.

TWO-STAGE VANE PUMP To improve the backing pressure and displacement at low pressure two stages are connected in series. ANTI-SUCKBACK SYSTEM If the Power Supply fails on stops, an anti-suck back device. Prevents air or oil the pump to be drawn back into the chamber being evacuated and operated by Solenoid coil. GAS BALLAST The gas ballast allows a quantity of air to be injected into the second stage of the pump during compression to reduce the partial pressure to the pumped gas below its saturated Vapour pressure and thus prevent condensation. The saturated vapour pressure of a gas is higher when it is hot and lower when it is cold. When gas ballasting is in use, there will be increase in ultimate pressure of the pump as well as the temperature. Power : 230V AC supply Optional: Moisture Trap Non Return Valve Vacuum Gauge Air Oil Mist Exhaust Filter
