product image
KJELDAHL DISTILLATION & DIGESTION (Combined Unit) (6 Test Mantle Type)

“Optics Technology” offers digestion and distillation combined unit. A maximum of 6 mantles which are made of a knitted layer of glass fabric combined with flexible heating elements, encased in mild steel housing. Temperature ranges from ambient to 350ºC controlled by Sunvic energy regulator with either a single control or individual controls, with corresponding indicating lamps. The distillation units are provided with a fume duct, which is held by clamps (provided with the unit) suspended on a stand having mobility for both horizontal and vertical movements. The digestion units are provided with the above features along with a condensing tank with individual condensing taps. They are placed on a MS angle stand with their respective controls supplied with / without any glass parts. Works on 220V Mains supply.

Send Message
product image
SAMPLING / DISPENSING BOOTHS

These are overhead clean air modules mounted with Stainless steel frame on the ground. Units can be built with / without casters so the clean enclosure can be moved over equipment or used to isolate a controlled process. It is basically used for filling, refilling weighing and sampling / Dispensing of Raw Material, Basic Compounds, Active Compounds. It works on the principal of Laminar Air Flow with HEPA Filters & Pre-Filters. This will act as a CLASS 100 Room. Protection of the personnel in the cabinet from the processed substances by vertical flow with Reverse Flow of clean air protection of the raw and intermediate products to be processed. Protection of the room where the cabinet is built up and environment from highly active substance which otherwise would disperse in the room and escape in the atmosphere unfiltered. Safe collection and deposition of substance released during work. Features: • M.S Powder Coated / Stainless Steel 304 Body • Hepa Filter (0.3 Micron) • Fine Filter (5 micron) • Pre-Filter (10 micron) at Arrestance 90% • Motor Blower Assembly • U.V. Light • Fluorescent Lamp Operating Switch • Static Pressure Manometer • Stainless Steel Standing Base • High quality HEPA filter provides protection for the product (filtration • efficiency of more than 99.97% at 0.3 micron). • Ultra-quiet noise level of not more than 65 dBA. • Durable and easy to clean stainless steel body. • Work area properly illuminated by diffused glare free fluorescent light. PVC Flexible Curtains on all the three sides. Specifications: Air Velocity : 90 ± 20 FPM (Average) Filtration Elements : Main Filters - HEPA Filter Prefilter : Washable non-woven polyester fibers. Light Intensity : 800-1000 Lux Power Supply : 220V Single Phase, 50 Hz. Model No. Working Size W x D x H OT-SB-215-MS/SS-A 2' X 2' X 6' OT-SB-215-MS/SS-B 3' X 2' X 6' OT-SB-215-MS/SS-C 3' X 3' X 6' OT-SB-215-MS/SS-D 4' X 2' X 6' OT-SB-215-MS/SS-E 4' X 3' X 6' OT-SB-215-MS/SS-G 6' X 4' X 6' OT-SB-215-MS/SS-H 6' X 6' X 6' OT-SB-215-MS/SS-I 8' X 4' X 6' OT-SB-215-MS/SS-J 8' X 6' X 6' OT-SB-215-MS/SS-K 8' X 8' X 6'

Send Message
product image
BOSTWICK CONSISTOMETER

The Bostwick Consistometer is the preferred choice for measuring consistency and flow rate in a variety of products. The unit is made from stainless steel which resists corrosion. You can use “Bostwick” on any viscous material such as sauces, salad dressings, paints, chemicals or cosmetics. The normal way to use the Consistometer is to measure the distance a sample flows in a given time interval. The Bostwick is a long trough with 0.5 cm graduations along the bottom. The trough is separated near one end by a spring loaded gate. This forms a chamber where the sample is loaded. The Bostwick also complies with the procedures established in Mill Spec R-81294D and ASTM F1080-93. The Bostwick Consistometer is built for ease of operation and heavy duty use. To clean it after a test, simply wash it out with water.

Send Message
