It is based on the Constant Rate of Traverse (CRT) principle. The sample is held between two jaws; the upper one is a stationary jaw while the other end is made to move at a known fixed speed with the help of Motor, Gear Box and Lead Screw arrangement. The load exerted on the Stationary jaw is sensed by a sensor connected with load cell which directly indicates the load in Digital form in Newton and kg.

DIGITAL SCREW GAUGE (MICROMETER)

Puf insulated to prevent thermal losses Eco friendly refrigerant CFC free Heavy Duty Compressor Temp. controlled by Microprocessor based Temp. Controller (Digital LED Display) Very low noise Lock & key arrangement Door is sealed with Silicon Gasket Heavy duty Castor Wheels Mounted for easy movability Works on 220 VAC / 50Hz Mains.

Air Flow: Vertical With Working table of S. S. 304 Body is made of Wooden/ M.S. Duly Powder Coated/ S.S. 304 Imported Mini Pleat HEPA Filter of 0.3µ of an efficiency of 99.97% down to 0.3µ media is of glass fiber & made of pleats back & frown in a anodized Aluminum frame. Prefilter of dry fiber washable type with the frame of on all the sides Confirm the international standards 209 E. Class 100 (As per USFED-STD. 209E) ISO Class 5 (As per ISO-14644.1), IEC 61010-1:2010, ISO 29463-5:2022 Statically Balanced motor blower Assembly (Heavy Duty) Velocity at the output of HEPA is 90 ± 20 FPM Noise level is very low Vibration is also very low Normal working fluorescent Light Static pressure Manometer U. V. Light 1 x 30/15 watts Front Door of Acrylic Sheet (Transparent) Gas cock Or any non standard size Optional: Magnahelic Gauge in place of Static Pressure Manometer. Digital Manometer U.V. Resistant Poly Carbonate sheet in place of Acrylic Sheet. Automatic Safety system for U.V. light. Automatic start system filtered Air & Normal light in Laminar Air Flow LCD display with soft touch switches for Motor, U.V. Light, F.V. Light & U.V. Timer Automatic motorised front door lifting arrangement Online transfer of data without any cable/wire Interference MICROPROCESSOR BASED TOUCH SCREEN DISPLAY SYSTEM Display of velocity with lower and upper safe limits. Display of total run time of instrument & timer for U.V. lamp Control of U.V. light to prevent the operator from U.V. rays as and when required. Automatic Door sensors to switch off the U.V. light when door is opened. Display of message for life of HEPA filter, U.V. light etc.

Working table of S.S. 304 Body is made of Wooden/ M.S. Duly Powder Coated/ S.S. 304 Imported Mini Pleat HEPA Filter of 0.3μ of an efficiency of 99.97% down to 0.3μ media is of glass fiber & made of pleats back & frown in a anodized Aluminum frame. Pre filter of dry fiber washable type with the frame of on all the sides. Confirm the international standards 209 E. Class 100 (As per USFED-STD. 209E) ISO Class 5 (As per ISO-14644.1), IEC 61010-1:2010, ISO 29463-5:2022 Statically Balanced motor blower Assembly (Heavy Duty) Velocity at the output of HEPA is 90 ± 20 FPM Noise level is very low Vibration is also very low. Normal working fluorescent Light. Static pressure Manometer U. V. Light 1 x 30/15 watts. Front Door of Acrylic Sheet (Transparent) Or any non standard size Optional: Magnahelic Gauge in place of Static Pressure Manometer. Digital Manometer U.V. Resistant Poly Carbonate sheet in place of Acrylic Sheet. Automatic Safety system for U.V. light. Automatic start system filtered Air & Normal light in Laminar Air Flow LCD display with soft touch switches for Motor, U.V. Light, F.V. Light & U.V. Timer Automatic motorised front door lifting arrangement Online transfer of data without any cable/wire Interference

“Optics Technology” Ductless Fume Hood basic offers variety of functionlities. Body is made of Wooden / M.S. Duly Powder Coated / S.S. 304. Eco friendly and cost effective. Mini pleat Hepa Filter of 0.3µ of an efficiency of 99.97% down to 0.3µ media is of glass fiber & made of pleates back & frow & packed in a anodized aluminum frame with carbon filter. Working table is covered with Chemical Resistant Granite. Front door is made of 6mm clear glass in Aluminium Frame duly Powder coated and connected with a counter weight balance through a nylon rope. The door will have the provision of vertical sliding facility. Internal Structure is coated with acid & fire resistance coating. Front door is made of 6mm clear toughened glass with easily sliding of up & down position. Exhaust blower of single phase Electric motor (1 H.P.) with 2500 RPM connected which is inbuilt in the hood. Ventilated base with storage cabinet of selection off drawer & doors. Light luminance of 140 lux with light lamp of anti corrosive. Power Supply: 220 V AC, Single Phase, 50 Hz. Optional: Base storage cabinet Air Flow Monitor (LCD Display). P.P. Sink with Swan Neck Water Tap Automatic motorized front door lifting arrangement. Scrubber System

“Optics Technology” Ductless Fume Hood basic offers variety of functionlities. Body is made of Wooden / M.S. Duly Powder Coated / S.S. 304. Eco friendly and cost effective. Mini pleat Hepa Filter of 0.3µ of an efficiency of 99.97% down to 0.3µ media is of glass fiber & made of pleates back & frow & packed in a anodized aluminum frame with carbon filter. Working table is covered with Chemical Resistant Granite. Front door is made of 6mm clear glass in Aluminium Frame duly Powder coated and connected with a counter weight balance through a nylon rope. The door will have the provision of vertical sliding facility. Internal Structure is coated with acid & fire resistance coating. Front door is made of 6mm clear toughened glass with easily sliding of up & down position. Exhaust blower of single phase Electric motor (1 H.P.) with 2500 RPM connected which is inbuilt in the hood. Ventilated base with storage cabinet of selection off drawer & doors. Light luminance of 140 lux with light lamp of anti corrosive. Power Supply: 220 V AC, Single Phase, 50 Hz. Optional: Base storage cabinet Air Flow Monitor (LCD Display). Touch Screen Model (Air Flow Touch Screen Display) P.P. Sink with Swan Neck Water Tap Automatic motorized front door lifting arrangement. Scrubber System

Double wall construction, all the electrical and optional accessories inside the chamber will be in between the first and second wall. Interiors acid resistant material coated with fire proof epoxy paint. Working table is covered with Granite Front door is made of 6mm clear Toughened glass. Counter weight balance Front Door. Vertical sliding facility & the front door can be stopped at any point. Exhaust blower consists of single phase motor connected with a PVC Exhaust Ducting. Standard ducting upto 6’ is provided. Optional: Base storage cabinet. P.P. Sink with Swan Neck Water Tap Air flow monitor (LCD Display). Automatic motorised front door lifting arrangement. Touch Screen Display with Air Flow Monitor. Scrubber System

Laboratory fume hoods are one of the most important components used to protect laboratory personnel from exposure to hazardous chemicals and agents used in the laboratory. Cabinet is made of : Wooden Body / M.S. Duly Powder Coated / Stainless Steel (304). Interiors acid resistant material coated with fire proof epoxy paint & further fixed on storage cabinet. Working table is covered with Granite Front door is made of 6mm clear Toughened glass. Counter weight balance Front Door. Vertical sliding facility & the front door can be stopped at any point. Exhaust blower consists of single phase motor connected with a PVC Exhaust Ducting. Standard ducting upto 6’ is provided. OR ANY NON STANDARD SIZE. Optional: Base Storage Cabinet P.P. Sink with Swan Neck Water Tap Air flow monitor (LCD Display) Automatic Motorized front door lifting arrangement Touch Screen Display with Air Flow Monitor Scrubber System
